Discover Hello Dave
-2.png?w=750&h=800)

Long and low steel frame, with aggressive trail taming geometry.
150mm Travel fork to take the biggest hits and keep you rolling
Versatile 1 x 12 Sram Eagle Groupsets
Wide, Supportive Rims and plenty of room for Big Rubber
Long and low steel frame, with aggressive trail taming geometry.
150mm Travel fork to take the biggest hits and keep you rolling
Versatile 1 x 12 Sram Eagle Groupsets
Wide, Supportive Rims and plenty of room for Big Rubber




Hello Dave Sizing and Geometry
Rider Height | Suggested Frame Size |
---|---|
5′3″ to 5′8″ (160cm-172cm) | Medium / 400mm |
5′8″ to 5′11″ (172cm-180cm) | Large / 430mm |
5′11″ to 6′3″ (180cm- 190cm) | X-Large /460mm |
MED/400mm | LRG/430mm | XL/460mm | ||
A | Head Angle (degrees) | 62.0 | 62.0 | 62.0 |
B | Head Tube (mm) | 110 | 120 | 140 |
C | Top Tube Effective(mm) | 595 | 625 | 670 |
D | Seat Tube Angle (degrees) | 77.0 | 77.0 | 77.0 |
E | Seat Tube C-T Actual (mm) | 400 | 430 | 460 |
F | Chainstays (mm) | 458 | 458 | 458 |
G | BB Drop (mm) | 50 | 50 | 50 |
H | Stack (mm) | 625 | 640 | 650 |
I | Reach (mm) | 450 | 480 | 520 |
J | Front Centre (mm) | 808 | 842 | 892 |
K | Wheelbase (mm) | 1261 | 1296 | 1345 |
