Scandal takes our years of experience from originating and evolving the sweetest handling 29er trail bikes and joins those delicious dots with a super light multi shaped and wall thickness alloy frame. Light, lively, and punchy without ever being punishing. Agile down the woods but totally sorted flat out in the mountains. Proper fork, big tyre space, dropper routing and killer value kit complete this classic fast, far, fun trail all-rounder.
Tough and responsive Aluminium Frame
130mm of Trail Eating Travel
1 x 12 Sram Eagle groupsets
Wide, Supportive Wheels and plenty of room for Big Rubber
Scandal Size and Geometry
| Rider Height | Suggested Frame Size |
|---|---|
| 5′3″ to 5′7″ (160cm-170cm) | Small / 15" |
| 5′6″ to 5′10″ (168cm-178cm) | Medium / 16.5" |
| 5′9″ to 6′2″ (175cm- 188cm) | Large /18" |
| 6′1″ to 6′4″ (185cm- 193cm) | X-Large / 19.5" |
| SML/15" | MED/16.5" | LRG/18" | XLG/19.5" | ||
| A | Head Angle (degrees) | 65.0 | 65.0 | 65.0 | 65.0 |
| B | Head Tube (mm) | 100 | 100 | 120 | 135 |
| C | Top Tube Effective(mm) | 601 | 623 | 639 | 657 |
| D | Seat Tube Angle (degrees) | 73.0 | 73.0 | 74.0 | 74.5 |
| E | Seat Tube C-T Actual (mm) | 380 | 420 | 460 | 500 |
| F | Chainstays (mm) | 435 | 435 | 435 | 435 |
| G | BB Drop (mm) | 58 | 58 | 58 | 58 |
| H | Stack (mm) | 609 | 609 | 629 | 644 |
| I | Reach (mm) | 415 | 437 | 460 | 480 |
| J | Front Centre (mm) | 730 | 752 | 783 | 809 |
| K | Wheelbase (mm) | 1159 | 1181 | 1212 | 1237 |
