Planet X Reiver SRAM Rival AXS E1 XPLR Gravel Bike

The Reiver is our Multi terrain speed machine a true gravel racer, if you are looking for a fast, forgiving and fun gravel bike then look no further. Whether picking your way through single track, attacking a technical climb or blasting linking tarmac sections the Reiver does it all – and fast. With all day comfort, multiple mounts for luggage, bottles, full mudguards and pannier racks the Reiver is also suitable for multi day adventures, commuting and everything in between.

Toray Carbon Frameset
Mavic Allroad Disc Wheelset 700c Disc Wheelset
Sram Rival AXS XPLR E1 13 speed Wireless Groupset
Semi Integrated Cockpit
Sram UDH Mech Hanger.
Full Luggage Mounts (Including Fork).
Tyre Clearance 700 x 50c

View less

$2,571.00

Shipping calculated at checkout.

Expect dispatch in 14 days

Available on Cycle to work

Colour

Midnight Marauder Bronze Raider

X-Small Small Medium Large X-Large

Rider Height	Suggested Frame Size
5′0″ to 5′5″	X-Small
5′5″ to 5′8″	Small
5′7″ to 5′10″	Medium
5′9″ to 6′0″	Large
6′0″ to 6′3″	X-Large

		XS	S	M	L	XL
A	Head Angle (degrees)	70	71	71	71	71
B	Head Tube (mm)	110	125	140	160	185
C	Top Tube Effective(mm)	517	538	551	571	588
D	Seat Tube Angle (degrees)	74	73	73	72.5	72.5
E	Seat Tube C-T Actual (mm)	450	490	520	540	560
F	Chainstays (mm)	435	435	435	435	435
G	BB Drop (mm)	69	69	69	69	69
H	Stack (mm)	530	548	562	581	604
I	Reach (mm)	365	370	379	388	397
J	Front Centre (mm)	596	597	611	626	643
K	Wheelbase (mm)	1021	1023	1036	1052	1069

Please note that our bikes are not supplied with pedals - these must be purchased separately

🔧 Customise your bike

Quantity

CBBIKE-REI-RAX-SML-BLU

Frame

Taking inspiration from multi day endurance gravel racing we set out to develop our own bike, eager to conquer this exciting form of offroad riding where speed and comfort are essential. Each tube profile has been designed to create a stiff yet forgiving ride, the dropped rear stays aid comfort while also giving an aerodynamic gain minimising watt loss to the rear wheel. The up-to-date geometry strikes a perfect balance between speed, handling and comfort. The semi-integrated cockpit gives a clean aesthetic, while the use of a conventional stem and handlebars allows freedom to upgrade and experiment with stem lengths and bar widths without unnecessary cost and complication. The use of a simple creak fee BSA threaded bottom bracket, and UDH hanger means easy maintenance wherever you are. Smaller riders will benefit from the slacker head angle and increased fork offset, minimising wheel toe overlap. Four bottle cage mounts, triple fork mounts, pannier rack and full mudguard mounts make the Reiver easy to live with on long days in the saddle in all but the worst conditions.

Groupset

Effortless Expanded
When the gravel gets tough, Rival XPLR AXS gets tougher. This workhorse groupset features the unmatched resilience and precision of a Full Mount rear derailleur with gravel-specific 13-speed gearing. This generation of Rival also gained better, more powerful brakes while shedding significant grams. It’s effortless performance for everyone.

Frame

Taking inspiration from multi day endurance gravel racing we set out to develop our own bike, eager to conquer this exciting form of offroad riding where speed and comfort are essential. Each tube profile has been designed to create a stiff yet forgiving ride, the dropped rear stays aid comfort while also giving an aerodynamic gain minimising watt loss to the rear wheel. The up-to-date geometry strikes a perfect balance between speed, handling and comfort. The semi-integrated cockpit gives a clean aesthetic, while the use of a conventional stem and handlebars allows freedom to upgrade and experiment with stem lengths and bar widths without unnecessary cost and complication. The use of a simple creak fee BSA threaded bottom bracket, and UDH hanger means easy maintenance wherever you are. Smaller riders will benefit from the slacker head angle and increased fork offset, minimising wheel toe overlap. Four bottle cage mounts, triple fork mounts, pannier rack and full mudguard mounts make the Reiver easy to live with on long days in the saddle in all but the worst conditions.

Groupset

Effortless Expanded
When the gravel gets tough, Rival XPLR AXS gets tougher. This workhorse groupset features the unmatched resilience and precision of a Full Mount rear derailleur with gravel-specific 13-speed gearing. This generation of Rival also gained better, more powerful brakes while shedding significant grams. It’s effortless performance for everyone.

1 / 2

📏 Sizing and Geometry

Rider Height	Suggested Frame Size
5′0″ to 5′5″	X-Small
5′5″ to 5′8″	Small
5′7″ to 5′10″	Medium
5′9″ to 6′0″	Large
6′0″ to 6′3″	X-Large

		XS	S	M	L	XL
A	Head Angle (degrees)	70	71	71	71	71
B	Head Tube (mm)	110	125	140	160	185
C	Top Tube Effective(mm)	517	538	551	571	588
D	Seat Tube Angle (degrees)	74	73	73	72.5	72.5
E	Seat Tube C-T Actual (mm)	450	490	520	540	560
F	Chainstays (mm)	435	435	435	435	435
G	BB Drop (mm)	69	69	69	69	69
H	Stack (mm)	530	548	562	581	604
I	Reach (mm)	365	370	379	388	397
J	Front Centre (mm)	596	597	611	626	643
K	Wheelbase (mm)	1021	1023	1036	1052	1069

🔧 Build Kit

🔧 Groupset

GBSRRIAKSE1-RR-2000-FM20	SRAM Rival AXS E1 Shift Brake System / Left Lever / Rear
GBSRRIAKSE1-FF-1000-FM20	SRAM Rival AXS E1 Shift Brake System / Right Lever / Front
RMSRRIXPLRAXSE1-M46	SRAM Rival AXS E1 13 Speed Rear Mech / Max 46T
CASRRI1351-1046	SRAM Rival XG-1351 13 Speed Cassette / 10-46 Tooth
CHSRRIAKSE1-120	SRAM Rival AXS E1 Chain / 120 Link
BSSPDBMH-15-SIN	SRAM Flat Mount Disc Brake Mounting Hardware / 15mm / S
BSAVCLRXYZ-160C	Avid Centreline Disc Brake Rotor / 160mm Centrelock
BBSRGPXS-MBL	SRAM GXP Bottom Bracket Spacer 2.5mm Single / Matt Black
BSAVHOSE-BB	SRAM Hydraulic Hose Fitting Kit Includes Barb And Olive
BSAVHOSE-OL	SRAM Hydraulic Hose Fitting Kit Includes Barb And Olive
FSSRAXSPP-1BA	SRAM Powerpack For AXS / 1 Battery

Finance with Newpay and Planet X

You could enjoy a credit limit of up to £5000, and once you’ve bought something, you can choose a payment plan to suit you. It’s super-easy to apply and we’ll even do a no-risk check first to see if you're eligible

More Info

Easy Assembly

Assembling your new bike couldn't be easier. Every bike comes expertly packed at least 95% pre assembled, with step by step instructions to get the bike ready to roll.

So you can get out on that first ride without delay!

Hand Built in South Yorkshire

All Planet X, On One, Holdsworth and Titus Bikes are expertly hand built to order in South Yorkshire.

Every bike is comprehensively inspected before shipping to ensure your bike is perfect when it arrives at your door.

Not sure on your size? Get Fitted!

Get fitted to your bike at Planet X Headquarters by one of our trained fitters.

With our Mini Bike Fit, we can advise on sizing, optimise your ride for maximum comfort and efficiency and help you make the right component choices. all for a refundable deposit of £25.
