Race Proven Carbon Climbing Machine
The Holdsworth Corsa is our pro-proven disc brake racer, featuring a light yet sprint stiff, hand laid, box section, Hi Modulus carbon fiber build. Slim dropped stays and tapered fork for fresh all day smoothness. Aggressive handling angles and stretched reach make the most of the tight tracking 12mm through axles and wide tyre clearance.

Discover Corsa

Race Proven, Light and Stiff Carbon frameset
Using a mix of T800 and T1000 carbon layup, the revised Corsa flies up the climbs, corners as if on rails, and sprints with confidence.
Powerful Disc Brakes
Brake later, corner quicker and don't worry about riding in the wet. You'll have controlled and powerful braking available every time you pull the lever.
Sensible Gearing to maximise your ride.
Using wide range road groupsets, you'll always be able to find the right gear to keep your legs turning; regardless of the time and distance spent in the saddle.
Clearance for up to 32mm Tyres
Don't get beaten up by the road. Smooth out the road ahead and ride faster, for longer, more often.
Race Proven, Light and Stiff Carbon frameset
Using a mix of T800 and T1000 carbon layup, the revised Corsa flies up the climbs, corners as if on rails, and sprints with confidence.
Powerful Disc Brakes
Brake later, corner quicker and don't worry about riding in the wet. You'll have controlled and powerful braking available every time you pull the lever.
Sensible Gearing to maximise your ride.
Using wide range road groupsets, you'll always be able to find the right gear to keep your legs turning; regardless of the time and distance spent in the saddle.
Clearance for up to 32mm Tyres
Don't get beaten up by the road. Smooth out the road ahead and ride faster, for longer, more often.

Corsa Sizing and Geometry

Rider Height Suggested Frame Size
5′4″ to 5′7″ XSmall (44)
5′6″ to 5′8″ Small (47)
5′7″ to 5′10″ Medium (51)
5′9″ to 6′1″  Large (54)
6'0″ to 6′4″  X-Large (57)



XS

S

M

L

XL
A Head Angle (degrees)

71.5

72.5

73

73

73
B Head Tube (mm)

115

135

155

170

190
C Top Tube C-C Effective (mm)

520

540

555

570

590
D Seat Tube Angle (degrees)

74.5

73.6

73

73

72.5
E Seat Tube C-T (mm)

440

470

510

540

570
F Chainstays (mm)

410

410

410

410

410
G BB Drop (mm)

68

68

68

68

68
H Stack (mm)

512

534

556

570

589
I Reach (mm)

377

382

384

396

404
J Front Centre (mm)

578

580

585

600

614
K

Wheelbase (mm)

978

981

985

1000

1015
